Arcade Cabinet DIY: 5 Creative Ideas: Compact, clever and buildable — five arcade cabinet ideas I actually used on real projects

I once promised a client a full-size arcade experience in a corner no bigger than a coat closet — she wanted Pac-Man and room for a plant. I learned fast that constraints force creativity: you can even visualize my cabinet in 3D before cutting a single board, which saves grief and glue stains. Small spaces can spark surprisingly big ideas, and in this piece I share five designs I’ve built or recommended over the last decade.

Bartop arcade: big fun, tiny footprint

Bartop cabinets sit on counters or short bases and deliver authentic controls without dominating a room. They’re great if you want arcade feel with minimal floor space; the downside is less vertical artwork space, so I often use strong marquee lighting to compensate. Budget tip: use MDF for structure and a vinyl wrap for a clean retro look that won’t break the bank.

Fold-down wall cabinet for multi-use rooms

I built a fold-down unit for a studio where every square foot mattered — the panel folds up like a Murphy table and hides the screen when guests arrive. The advantages are obvious: multi-function and surprise reveal; the challenge is the hinge mechanism and wiring, which need careful routing so cables don’t pinch. If you’re cautious about layout, I recommend planning your hinge and wiring path early on to avoid mid-build headaches.

Modular control panel: swap layouts in minutes

My favorite hack is a modular control deck: a removable panel held by thumbscrews so you can swap flight sticks for joysticks or change button layouts for different games. It’s slightly more work up front but offers huge flexibility for families who can’t agree on controls. To create a precise layout drawing of the panel and cabinet internals first — trust me, measuring twice saves a week of re-drilling.

save pin

Mini retro cabinet with bold graphics

If you want charm, go retro: laminate a small cabinet with eye-catching side art and a classic CRT-style bezel around a modern LCD. The outcome is nostalgia without CRT weight or heat; the trade-off is that authentic wood finishes and detailed art add cost and time. My trick is to print high-res vinyl wraps and seal edges with simple trim to get a pro look without custom painting.

save pin

Modern integrated unit with storage and screens

For a cleaner living-room-friendly approach, design a slim cabinet that houses a monitor, storage for controllers, and cable channels so everything tucks away. This works great for shared spaces and gives a polished, furniture-like feel; the downside can be reduced ventilation, so I design discreet vents and an accessible rear panel. If you want to quickly test different control panel arrangements and proportions, mock it up at scale before cutting wood.

save pin

FAQ

Q: What basic tools do I need for an arcade cabinet DIY?

A: A circular saw or jigsaw, drill with screwdriver bits, router or round-over bit for edges, clamps, and sandpaper are the essentials. Optional but helpful: a cabinet hinge kit and a multimeter for wiring checks.

Q: Which wood is best for a DIY cabinet?

A: MDF is inexpensive, stable, and easy to paint or wrap, while plywood (birch) is stronger and looks nicer if you want stained edges. Avoid particle board if you expect moisture or heavy wear.

Q: How much floor space should I plan for?

A: Bartop units can fit on a 24–30 inch deep shelf; full upright cabinets typically need a 24–30 inch square footprint. Always account for clearance to sit or stand comfortably in front of controls.

Q: What controls and buttons should I use?

A: Sanwa or Seimitsu-style arcade parts are durable and feel great for fighting games, while budget microswitch buttons work fine for casual play. Modular panels let you experiment without committing to one layout.

Q: Can I use an LCD instead of an old CRT?

A: Yes — modern LCDs are lighter, cooler, and easier to source. You’ll sacrifice a bit of authentic CRT scanline look, which you can emulate with shaders if you use a Raspberry Pi or emulator frontend.

Q: How much should I budget for a DIY cabinet?

A: A simple bartop can be built for $100–$250 using MDF, a small monitor, and basic parts; full upright builds commonly run $300–$800 depending on finish and electronics. Plan extra for control upgrades or high-quality monitors.

Q: How do I handle wiring and electrical safety?

A: Keep mains wiring tidy, use fused power entries, and separate low-voltage wiring (USB, HDMI) from mains where possible; always ground chassis parts. For authoritative safety guidance, consult the U.S. Consumer Product Safety Commission (CPSC) at https://www.cpsc.gov and follow local electrical codes.

Q: Where can I find plans or visual previews?

A: Many makers share plans on community sites and GitHub, and I recommend mockups or 3D previews before cutting material to verify proportions. If you’re new, start with a bartop template and adapt dimensions to your space.
